ABB

Terra AC 22kW

A commercial-grade three-phase 22kW charger from Swiss engineering leader ABB, with the longest residential warranty in its class.

Estimated charger price

around $1,979

Estimated installation

around $700–$1,500

Typical installation estimate for a straightforward home installation. Longer cable runs, switchboard upgrades, three-phase work, trenching or other site requirements can increase the cost.

FIND MY CHARGER Back to chargers

Overview

The ABB Terra AC Wallbox supports up to 22 kW three-phase charging, with single-phase variants available up to 7.4 kW. It provides OCPP 1.6 connectivity, RFID authentication, built-in energy metering and support for external energy-meter integration for dynamic load management. ABB's current technical documentation lists IP55 and IK10 protection. The standard warranty is two years, with extended-warranty options available separately.

Key highlights

22 kW three-phase

Type 2 socket

OCPP 1.6

RFID authentication

Dynamic load-management support with compatible external meter

IP55 / IK10

2-year standard warranty

Best for

Three-phase installations using a 22 kW AC wallbox with OCPP and RFID
Households wanting warranty depth (2-year standard warranty)
Semi-commercial contexts (RFID access control)
Users trusting global brand heritage

Not ideal for

— Single-phase homes
— Users seeking solar surplus diversion (not built-in)

Using this charger at home in Australia

This charger supports higher AC charging speeds where both your home's electrical supply and your EV's onboard AC charger allow. Confirm your home's phase support with a licensed electrician, and check your EV's maximum AC charging capability.

Where supported and correctly configured, load management can reduce EV charging power when other household loads increase, helping keep total demand within the configured site limit.

OCPP support allows the charger to communicate with compatible OCPP charging-management platforms. OCPP support by itself does not guarantee integration with a home battery, solar inverter, electricity tariff or every third-party platform.

The manufacturer lists an IP55 enclosure rating for this charger. The final mounting location should follow the manufacturer's installation requirements and be confirmed by the installer.

A dedicated home EV charger should be installed by a licensed electrician. The installer should confirm the circuit design, switchboard capacity, protection requirements and any applicable local electricity-network requirements.

Key specifications

Estimated installationaround $700–$1,500

Power22 kW

PhaseThree-phase

CableUntethered (socket)

Weather ratingIP55

Warranty3 years

Solar support—

OCPPYes

Load balancingYes

App controlYes

Charger prices are estimates based on publicly available pricing we could verify and may change with retailer offers, promotions and product configuration. Installation is additional.

Typical installation estimate for a straightforward home installation. Longer cable runs, switchboard upgrades, three-phase work, trenching or other site requirements can increase the cost.
