Nissan home EV chargers
Find suitable home charger options for Nissan electric vehicles including the Ariya.
Nissan EV home-charging capability varies significantly by model and grade. Current ARIYA models and recent Australian LEAF models use Type 2 for AC charging, but their onboard charging limits are different.
Current Australian ARIYA specifications provide 7.4 kW single-phase AC charging on the 63 kWh grades. The 87 kWh Advance+ can be equipped with a 22 kW three-phase onboard charger, while the Evolve e-4ORCE has 22 kW three-phase AC charging as standard. Recent Australian LEAF models use a 6.6 kW Type 2 onboard AC charger.
Choose the home charger around the exact Nissan model and grade, the property's electrical supply and the household's charging needs. A 22 kW wallbox only provides a charging-speed benefit where both the Nissan and the home installation can support that rate.
Find the Right Charger for Your EV
The right home charger depends on your exact EV, home electrical supply, solar setup and charging needs. Tell us about your vehicle and home to get a tailored recommendation.
Nissan EV charging FAQs
What charging connection do Nissan EVs use at home?
The current Nissan ARIYA uses a Type 2 AC interface as part of its CCS2 charging connection. Recent Australian LEAF models also use a Type 2 inlet for AC charging. The LEAF's separate CHAdeMO connection is for DC fast charging and does not determine which AC home wallbox you use.
How fast can I charge a Nissan ARIYA at home?
Current Australian ARIYA 63 kWh grades have a maximum 7.4 kW single-phase onboard AC charger. The 87 kWh Advance+ can be fitted with a 22 kW three-phase onboard charger, while the Evolve e-4ORCE has 22 kW three-phase AC charging as standard. Actual charging power also depends on the home supply and wallbox.
How fast can I charge a Nissan LEAF at home?
Recent Australian Nissan LEAF and LEAF e+ models use a 6.6 kW onboard AC charger with a Type 2 connection. A wallbox rated above that level will not make those vehicles accept more than their onboard AC limit.
Do I need a 22 kW home charger for a Nissan?
Only certain ARIYA grades can make use of 22 kW three-phase AC charging. A 22 kW wallbox provides no charging-speed advantage to a Nissan whose onboard AC charger is limited to 7.4 kW or 6.6 kW. It also requires a suitable three-phase home installation to deliver 22 kW.
Can I charge my Nissan from a regular power point?
Yes, where suitable portable charging equipment is available for the vehicle and the outlet is appropriate for EV charging. Charging from a standard Australian power point is much slower than using a dedicated wallbox. Avoid extension leads and power boards, and consult a licensed electrician if you are unsure whether the electrical setup is suitable.
Information is provided as general guidance only. Always confirm details with your installer or manufacturer.
